MOXA 45MR-2404 Remote I/O Module






- Model: 45MR-2404




MOXA 45MR-2404 INTRODUCTION
Moxa’s ioThinx 4500 Series (45MR) Modules are available with
DI/Os, AIs, relays, RTDs, and other I/O types, giving users a wide variety of
options and allowing them to select the I/O combination that best fits their
target application. With its unique mechanical design, hardware installation,
and removal can be done easily without tools, greatly reducing the amount of
time required to set up and replace the modules.
Easy Tool-Free Installation and Removal
The ioThinx 4500 Series has a unique mechanical design that reduces the time required for installation and removal. Screwdrivers and other tools are not required for any part of the hardware installation, including mounting the device on a DIN rail and connecting the wiring for communication and I/O signal acquisition. Furthermore, no tools are required to remove the ioThinx from a DIN rail. Removing all modules from a DIN rail is also easy using the latch and release tab.
As an Authorized Distributor of MOXA, Manufacturers Automation Inc. (ManuAuto) offers a wide variety of Industrial Automation and Communication products across North America, including Canada (Ontario, Toronto) and the US. Buy MOXA 45MR-2404 Remote I/O Module online at a competitive price, with on-time delivery and fast shipping services. Our certified engineers are always available to support you.
You can also find the 45MR-2404-T and 45MR-2600 models in the MOXA ioThinx 4500 Series (45MR) Modules.
MOXA 45MR-2404 CERTIFICATIONS
Remote I/O Modules : Input/Output Interface | |
Digital Input and Output | No |
Analog Input and Output | No |
System Power Input Channels | No |
Field Power Input and Output | No |
Thermocouple Channels | No |
RTD Channels | No |
Relays | Yes : 4 x Channels (Form A, 30 VDC/250 VAC, 2 A) |
Serial Ports | No |
Isolation | Yes : 3k VDC or 2k Vrms |
Remote I/O Modules : Serial Interface | |
Connector | - |
Serial Standards | - |
Serial Communication Parameters | - |
Serial Signals | - |
Switch and Hub : Interface | |
Ethernet ports | No |
Remote I/O Modules : General | |
MTBF | 1,955,805 hrs |
Remote I/O Modules : Power Requirements | |
Power Connector | Spring-type Euroblock terminal |
Input Voltage | System: 12 to 48 VDC, Field: 12 to 24 VDC |
Power Consumption | System: 44 mA @ 3.3 VDC, Field: 31.2 mA @ 12 VDC, 24.7 mA @ 24 VDC |
Remote I/O Modules : Physical Characteristics | |
Housing | Plastic |
Dimensions | 19.5 x 99 x 60.5 mm (0.77 x 3.90 x 2.38 in) |
Weight | 88.4 g (0.195 lb) |
Installation | DIN-rail mounting |
Operating Temperature | -20 to 60°C (-4 to 140°F) |
Storage Temperature | -40 to 85°C (-40 to 185°F) |
Ambient Relative Humidity | 5 to 95% (non-condensing) |
Standards and Certifications | EMC: EN 55032/35; EMI: CISPR 32, FCC Part 15B Class A; EMS: IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV, IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m, IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV, IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV, IEC 61000-4-6 CS: 3 V, IEC 61000-4-8 PFMF; Shock: IEC 60068-2-27; Vibration: IEC 60068-2-6; Safety: UL 61010-2-201; Hazardous Locations: ATEX, Class I Division 2; Green Product: RoHS, CRoHS, WEEE; Telcordia SR332 |
Altitude | Up to 4000 meters |
