MOXA 45MR-3810 Remote I/O Module
- Model: 45MR-3810
MOXA 45MR-3810 INTRODUCTION
Moxa’s ioThinx 4500 Series (45MR) Modules are available with
DI/Os, AIs, relays, RTDs, and other I/O types, giving users a wide variety of
options and allowing them to select the I/O combination that best fits their
target application. With its unique mechanical design, hardware installation,
and removal can be done easily without tools, greatly reducing the amount of
time required to set up and replace the modules.
Easy Tool-Free Installation and Removal
The ioThinx 4500 Series has a unique mechanical design that
reduces the time required for installation and removal. Screwdrivers and other
tools are not required for any part of the hardware installation, including
mounting the device on a DIN rail and connecting the wiring for communication
and I/O signal acquisition. Furthermore, no tools are required to remove the
ioThinx from a DIN rail. Removing all modules from a DIN rail is also easy
using the latch and release tab.
As an Authorized Distributor of MOXA, Manufacturers Automation Inc. (ManuAuto) offers a wide variety of Industrial Automation and Communication products across North America, including Canada (Ontario, Toronto) and the US. Buy MOXA 45MR-3810 Remote I/O Module online at a competitive price, with on-time delivery and fast shipping services. Our certified engineers are always available to support you.
You can also find the 45MR-3810-T and 45MR-3800 models in the MOXA ioThinx 4500 Series (45MR) Modules.
MOXA 45MR-3810 CERTIFICATIONS
Remote I/O Modules : Input/Output Interface | |
Digital Input Channels | No |
Digital Output Channels | No |
Analog Input Channels | 8 x (-10 to 10 VDC 0 to 10 VDC) |
Analog Output Channels | No |
System Power Input Channel | No |
Field Potential Output Channels | No |
Field Power Input Channels | No |
Thermocouple Channels | No |
RTD Channels | No |
Isolation | 3k VDC or 2k Vrms |
Relays | No |
Remote I/O Modules : General | |
MTBF | 2,478,459 hrs |
Remote I/O Modules : Power Requirements | |
Power Connector | Spring-type Euroblock terminal |
Power Consumption | 187 mA @ 3.3 VDC |
Remote I/O Modules : Physical Characteristics | |
Housing | Plastic |
Dimensions | 19.5 x 99 x 60.5 mm (0.77 x 3.90 x 2.38 in) |
Weight | 79 g (0.175 lb) |
Installation | DIN-rail mounting |
Operating Temperature | -20 to 60°C (-4 to 140°F) |
Storage Temperature | -40 to 85°C (-40 to 185°F) |
Ambient Relative Humidity | 5 to 95% (non-condensing) |
Standards and Certifications | EMC, EMI, EMS, Shock, Vibration, Safety, Hazardous Locations, RoHS, CRoHS, WEEE |
