MOXA AWK-1137C-US Wireless Access Point

MOXA AWK-1137C-US Wireless Access Point
  • Model: AWK-1137C-US
$0.00
Ex Tax: $0.00

MOXA AWK-1137C-US FEATURES

  • 2 x 10/100BaseT(X) Ports (RJ45 connector)
  • IEEE 802.11a/b/g/n compliant client
  • Comprehensive interfaces with one serial port and two Ethernet LAN ports
  • Client-based millisecond-level Turbo Roaming
  • 2x2 MIMO future-proof technology
  • Integrated robust antenna and power isolation
  • Anti-vibration design
  • Compact size for your industrial applications
  • Easy setup and deployment with AeroMag
Over 40 Years in Business
Over 40 Years in Business
Successful track record across Canada
Full Engineering Services
Full Engineering Services
A powerhouse to provide consultation, training, and support
Strong Brand Portfolio
Strong Brand Portfolio
Top-notch products from superb global and local suppliers
Advanced Technologies
Advanced Technologies
From legacy and mainstream to advanced Industry 4.0

MOXA AWK-1137C-US INTRODUCTION

The AWK-1137C is an ideal client solution for industrial wireless mobile applications. It enables WLAN connections for both Ethernet and serial devices and is compliant with industrial standards and approvals covering operating temperature, power input voltage, surge, ESD, and vibration. The AWK-1137C can operate on either the 2.4 or 5 GHz bands and is backward-compatible with existing 802.11a/b/g deployments to futureproof your wireless investments.


MOXA AWK-1137C-US CERTIFICATIONS


Access Point : Interfaces
Modulation Type DSSS, MIMO-OFDM, OFDM
10/100/1000BaseT(X) Ports 2 X RJ45
PoE Ports No
Wireless Security WEP encryption (64-bit and 128-bit), WPA/WPA2-Enterprise (IEEE 802.1X/RADIUS, TKIP, AES), WPA/WPA2-Personal
WLAN Operation Mode Client, Client-Router, Slave, Sniffer
Security HTTPS/SSL, RADIUS, SSH
WLAN Standards 802.11a/b/g/n, 802.11i Wireless Security
Transmission Rates 802.11b: 1 to 11 Mbps, 802.11a/g: 6 to 54 Mbps, 802.11n: 6.5 to 300 Mbps
Digital Inputs No
Console Port -
Access Point : Power Requirement
Input Current -
Input Voltage 9 to 30 VDC
Power Consumption 11.7 W (max.)
Reverse Polarity Protection Yes
Access Point : Physical Characteristics
Humidity 5 to 95% (non-condensing)
Dimensions Packaged 77.1 x 115.5 x 26 mm (3.035 x 4.55 x 1.024 in)
IP Rating IP30
Weight (PACKAGED) 0.47kg (1.03 lb)
Standards and Certifications IEEE 802.1Q for VLAN Tagging IEEE 802.3 for 10BaseT IEEE 802.3u for 100BaseT(X)
Safety EN 60950-1, UL 60950-1
EMC EN 61000-6-2/-6-4, EN 55032/24
EMI CISPR 22, FCC Part 15B Class A
Housing Metal
EMS IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV, IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m, IEC 61000-4-4 EFT: Power: 2 kV; Signal: 1 kV, IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV, IEC 61000-4-6 CS: 10 V IEC 61000-4-8 PFMF,
Installation DIN-rail mounting, Wall mounting (with optional kit)
Operating Temperature 0 to 60°C (32 to 140°F)
Storage Temperature -40 to 85°C (-40 to 185°F)
Access Point : General
Management DHCP Server/Client, HTTP, IPv4, LLDP, SMTP, SNMPv1/v2c/v3, Syslog, TCP/IP, Telnet, UDP, Proxy ARP, Wireless Search Utility, VLAN, MXview, MXconfig
MTBF 1,125,942 hrs
LED Indicators SYS, LAN1, LAN2, WLAN, Serial
