MOXA DR-75-24 DIN-rail Power Supply

Tags: Accessories , Power Accessories , DIN-Rail Power Supplies , Industrial Accessories , Power Supplies , MOXA DR Power Supply Series

Model: DR-75-24

Based on 0 reviews. - Write a review

$0.00

Ex Tax: $0.00

Add to Cart

Buy Now Enquire Now

Add to Wish List Compare this Product

Datasheet

MOXA DR-75-24 FEATURES

85 to 264 VAC, 120 to 370 VDC input power range
24 VDC (76.8 W) output power range
DIN-rail mounting
-10 to 60°C operating temperature range

Over 40 Years in Business

Successful track record across Canada

Full Engineering Services

A powerhouse to provide consultation, training, and support

Strong Brand Portfolio

Top-notch products from superb global and local suppliers

Advanced Technologies

From legacy and mainstream to advanced Industry 4.0

Description
Specifications

MOXA DR-75-24 INTRODUCTION

The DR Power Supply Series provides a reliable 24/48 VDC power source for industrial control systems. The Series has rugged, compact enclosures, and can operate reliably in temperatures between -10 and 60°C. The DR Power Supply Series has passed a 100% full load burn-in test and is UL/CUL listed, TÜV/CB certified, and CE marked.

As an Authorized Distributor of MOXA, Manufacturers Automation Inc. (ManuAuto) offers a wide variety of Industrial Automation and Communication products across North America, including Canada (Ontario, Toronto) and the US. Buy MOXA DR-75-24 DIN-rail Power Supply online at a competitive price, with on-time delivery and fast shipping services. Our certified engineers are always available to support you.

End of Life Product - Replacement Available

Please note that the DR Power Supply Series has been phased out, and replaced by the MOXA HDR Series and MOXA NDR Series.

MOXA DR-75-24 CERTIFICATIONS

Power Supply : Power Requirements
Input	Voltage: 85 to 264 VAC (47 to 63 Hz), 120 to 370 VDC; Typical Current: 0.96 A @ 230 VAC, 1.6 A @ 115 VAC; Inrush Current (cold start): 40 A @ 230 VAC, 20 A @ 115 VAC
Operating Voltage	-
Output	Wattage: 76.8 W; Voltage: 24 VDC; Current Rating: 0 to 3.2 A
Over-voltage Protection	29 to 33 V (Shut down operating voltage, repower on to recover)
Overload Protection	105-150% (Constant current limiting, recovers automatically after fault condition is removed)
Reverse Polarity Protection	-
Power Supply : Physical Characteristics
Dimensions	55.5 x 100 x 125.2 mm (2.19 x 3.94 x 4.93 in)
Housing	-
Weight	550 g
Ambient Relative Humidity	20 to 90% (non-condensing)
Operating Temperature	-10 to 60°C (14 to 140°F)
Storage Temperature	-
Installation	DIN-rail mounting
Standards and Certifications	EMC: EN 50082-2, EN 55022 Class B, EN 61000-3-2 Class A, ENV 50204; Safety: EN 60950-1
MTBF	-
Power Supply : Supported Series
Supported Series	-
