PULS SL30.100 DIN-rail Power Supply








PULS SL30.100 DIN-rail Power Supply
- Model: SL30.100
$0.00
Ex Tax: $0.00
PULS SL30.100 FEATURES
- Input: AC 208 - 240V
- Output: 24 to 28V / 30A
- 92.5% efficiency
- Ideal for parallel operation
- Simple fusing

Over 40 Years in Business
Successful track record across Canada

Full Engineering Services
A powerhouse to provide consultation, training, and support

Strong Brand Portfolio
Top-notch products from superb global and local suppliers

Advanced Technologies
From legacy and mainstream to advanced Industry 4.0
PULS SL30.100 INTRODUCTION
The SL30.100 is a DIN-rail power supply with an AC 208 - 240V Input.
As an Authorized Distributor of PULS, Manufacturers Automation Inc. (ManuAuto) offers a wide variety of Industrial Automation and Communication products across North America, including Canada (Ontario, Toronto) and the US. Buy PULS SL30.100 DIN-rail Power Supply online at a competitive price, with on-time delivery and fast shipping services. Our certified engineers are always available to support you.
You can also find the SL5.100 and SL4.100 models in the PULS DIN-rail Power Supplies for 1-phase Systems Series.
PULS SL30.100 CERTIFICATIONS
PULS Power Supply : Input Data | |
Input Voltage Range | AC: 180 to 276 VAC |
Nominal Input Voltage | - |
Input Frequency Range | 47 to 63 Hz |
Input Current | < 9A eff |
Power Factor | - |
Crest Factor | - |
Inrush Current | At 276 VAC: < 33A |
Input Fuse | No |
PULS Power Supply : Output Data | |
Output Voltage Range | 24 to 28 V |
Nominal Output Voltage | 24 VDC |
Output Current | 17.1 A at 28 V, 20 A at 24 V |
Output Power | 720 W |
Power Boost | - |
Output Capacitance | - |
PULS Power Supply : Protection Features | |
Overload Protection | Yes |
Reverse Input Polarity Protection | No |
Over-Temperature Protection | No |
Input Transient Protection | No |
Output Transient Protection | No |
Short Circuit Protection | Yes |
Output Overvoltage Protection | Yes: typ. 33V |
PULS Power Supply : General | |
MTBF | No |
Connection Method | Screw terminals |
AC/DC OK | AC: Yes |
LED Indicators | 1 green LED |
Remote ON / OFF Function | - |
IO-Link Interface | - |
PULS Power Supply : Physical Characteristics | |
Operating Temperature | 0° to 70°C |
Storage Temperature | -25° to 85°C |
Relative Humidity Range | 5 to 95% r.H |
Altitude Range | - |
Derating | Between +60 to +70 °C: typ. 18W/K |
Dimensions | 240 mm x 124 mm x 112 mm |
Weight | 2000 g |
Mounting Type | DIN rail |
Housing | Sealed metal |
Standards and Certifications | IEC 60950, UL 508, UL 60950, EMC |
