Proxim Edge Multipoint MP-1066-CPE-WD Point-to-Multipoint Radio
  • Model: Edge Multipoint MP-1066-CPE-WD
Proxim Proxim
Based on 0 reviews. - Write a review
$0.00
Ex Tax: $0.00
Add to Cart
Buy Now Enquire Now
Add to Wish List Compare this Product

Proxim Edge Multipoint MP-1066-CPE-WD FEATURES

  • Flexible channel planning with support for 5.900 to 6.425 GHz
  • High throughput MIMO 2x2:2 with radio rates of 300 Mbps at 40 MHz
  • High-power radio delivering up to 25 dBm (2 RF)
  • High reliability and advanced QoS for quad-play applications
  • Dual IPv4 and IPv6 stacks
Over 40 Years in Business
Over 40 Years in Business
Successful track record across Canada
Full Engineering Services
Full Engineering Services
A powerhouse to provide consultation, training, and support
Strong Brand Portfolio
Strong Brand Portfolio
Top-notch products from superb global and local suppliers
Advanced Technologies
Advanced Technologies
From legacy and mainstream to advanced Industry 4.0

Proxim Edge Multipoint MP-1066-CPE-WD INTRODUCTION

The Proxim Edge Multipoint 1066 CPE Series LNK is a highly reliable outdoor, high throughput point-to-point system designed to deliver years of reliable service and priced to fit cost-sensitive medium-range backhaul projects. The Edge Quickbridge is powered by Proxim’s advanced Wireless Outdoor Router Protocol (WORP). Among the many benefits of WORP are its effective use of bandwidth, granular service level management, and an advanced Quality of Service engine.

Powered by WORP®

Proxim, WORP enables the most efficient wireless broadband access possible in a packet-based network. Advanced QoS controls, committed interface rates, latency controls, IGMP snooping, and native multicast support allow granular service level management and the best video performance available in this product class.

Advanced Interference Management

Proxim ClearConnect™ combines multiple dynamic technologies and delivers the best interference management solution available.

Rugged Reliability

IP67-rated metal enclosure to ensure years of reliable service in harsh environments, including high winds, high salt, and temperature extremes.

Secure

AES 128 encryption with Radius-based authentication and secure management through SSL/ TLS1.2, SSH, and SNMPv3.

As an Authorized Distributor of Proxim, Manufacturers Automation Inc. (ManuAuto) offers a wide variety of Industrial Automation and Communication products across North America, including Canada (Ontario, Toronto) and the US. Buy Proxim Edge Multipoint MP-1066-CPE-WD Point-to-Multipoint Radio online at a competitive price, with on-time delivery and fast shipping services. Our certified engineers are always available to support you.

Wireless Radio : Interfaces
Ethernet -
Wired Ethernet One auto MDI-X RJ45 10/100/1000Mbps Ethernet with PoE in
Wireless Protocol WORP® (Wireless Outdoor Router Protocol)
Extension -
Management -
Wireless Radio : Radio Specifications
Radio Type -
MIMO 2x2:2
Modulation OFDM BPSK-QAM64
Frequency 5.900 – 6.425 GHz (Subject to Country Regulations)
Channel Size 5, 10, 20 and 40 MHz
Data Rate Upto 300 Mbps
TX Power Up to 25 dBm (dual chain)
TX Power Control 0 - 22 dB, in 1 dB steps. Automatic TPC with configurable EIRP limit
Throughput -
Other -
Wireless Radio : Antenna
Antenna Type Integrated 2x2 MIMO 15 dBi Dual Polarized 33 degree Panel Antenna
Beam Width -
Receive Gain -
Transmit Gain -
Wireless Radio : Network
Modes Bridging, Routing (RIP v2 and IP tunneling)
IP Stack IPv4 and IPv6 simultaneously
Latency -
Gateway Features 802.1Q: Management VLAN. Transparent, Access, Trunk and Mixed mode. QinQ double tagging
VLAN 802.1Q: Management VLAN. Transparent, Access, Trunk and Mixed mode. QinQ double tagging
Wireless Radio : Management
Remote Telnet and SSH, Web GUI and SSL/TLS1.2, TFTP, SNMPv3
SNMP SNMP v1-v2c-v3, RFC-1213, RFC-1215, RFC-2790, RFC-2571, RFC-3412, RFC-3414, Private MIB
Bluetooth Low Energy -
Multi-Language Support Web Interface available in English, French, Spanish, and Chinese
Other Syslog, sFlow™ agent, SNTP and local time, Spectrum analyzer
Wireless Radio : Security
Encryption AES 128
Authentication Internal MAC Address Control List, Radius based Authentication (with VLAN and QoS provisioning)
802.1X Support Yes
Wireless Radio : Wireless
AP-AP Communications -
RF Environment -
Wireless Radio : General
MTBF >200 000 hours
Wireless Radio : Power Requirement
Input Power -
Output Power -
Power Consumption 10 W typical, 12 W max
Power Standards 802.3af/at
Wireless Radio : Physical Characteristics
Temperature -30° to 55° Celsius (-22° to 131° Fahrenheit)
Humidity 100% relative humidity
IP Rating IP67
Dimensions Packaged 310 x 226 x 98 mm (12.2 x 8.9 x 3.85 in)
Dimensions Unpackaged 170 x 217 x 56 mm (6.7 x 8.55 x 2.2 in)
Weight (PACKAGED) 2.15 kg (4.74 lbs)
Weight (UNPACKAGED) 1.20 kg (2.65 lbs)
Standards and Certifications IEC 62368-1:2016 & 60950-22:2016, EN 62368-1:2014 + A11:2017 & 60950-22:2017
Safety IEC 62368-1:2016 & 60950-22:2016, EN 62368-1:2014 + A11:2017 & 60950-22:2017
Wind Loading 180 km/h (112.5 mph)
Wireless Radio : Standards and Protocols
Synchronization -
Wireless Radio : Package Checklist
Package Contents One Edge MP-1066-CPE with integrated antenna, One M25 weather proofing cable gland, One wall mounted power injector with US to EU plug adapter, One pair of hose clamps, One Grounding kit, One Quick Installation Guide
